RA-C Single-split Crossed Roller Bearings
Datasheet
| Bearing No. | Dimensions | Mass | ||||||
| d | D | dp | BB1 | d0 | ds | Dh | ||
| – | mm | mm | mm | mm | mm | mm | mm | kg |
| RA 5008C | 50 | 66 | 57 | 8 | 1.5 | 53.5 | 60.5 | 0.08 |
| RA 6008C | 60 | 76 | 67 | 8 | 1.5 | 63.5 | 70.5 | 0.09 |
| RA 7008C | 70 | 86 | 77 | 8 | 1.5 | 73.5 | 80.5 | 0.1 |
| RA 8008C | 80 | 96 | 87 | 8 | 1.5 | 83.5 | 90.5 | 0.11 |
| RA 9008C | 90 | 106 | 97 | 8 | 1.5 | 93.5 | 100.5 | 0.12 |
| RA 10008C | 100 | 116 | 107 | 8 | 1.5 | 103.5 | 110.5 | 0.14 |
| RA 11008C | 110 | 126 | 117 | 8 | 1.5 | 113.5 | 120.5 | 0.15 |
| RA 12008C | 120 | 136 | 127 | 8 | 1.5 | 123.5 | 130.5 | 0.17 |
| RA 13008C | 130 | 146 | 137 | 8 | 1.5 | 133.5 | 140.5 | 0.18 |
| RA 14008C | 140 | 156 | 147 | 8 | 1.5 | 143.5 | 150.5 | 0.19 |
| RA 15008C | 150 | 166 | 157 | 8 | 1.5 | 153.5 | 160.5 | 0.2 |
| RA 16013C | 160 | 186 | 172 | 13 | 2 | 165 | 179 | 0.59 |
| RA 17013C | 170 | 196 | 182 | 13 | 2 | 175 | 189 | 0.64 |
| RA 18013C | 180 | 206 | 192 | 13 | 2 | 185 | 199 | 0.68 |
| RA 19013C | 190 | 216 | 202 | 13 | 2 | 195 | 209 | 0.69 |
| RA 20013C | 200 | 226 | 212 | 13 | 2 | 205 | 219 | 0.71 |
